Shear Safety Joint
ASTA Shear Safety Joint is designed with special safety integral slot key to protect shear from rotational torque. This product consists of two sections (male and female section) and several shear pins to joint both sections. Made from alloy steel for long lifespan, ASTA Shear Safety Joint also uses special rubber seals to endure 350º F ~ 450º F temperature range steam.
| Size (in) | Min. Dia (in) | Length(in) | API 5CT Thread Connection | Available Shear Strength (lbs)* | P/N |
|---|---|---|---|---|---|
| 2-3/8 | 2.875 | 8 | NUE 10 RD or EUE 8 RD | 40.000 to 50.000 | 02-10.30-2.375 |
| 2-7/8 | 3.500 | 10 | NUE 10 RD or EUE 8 RD | 40.000 to 50.000 | 02-10.30-2.875 |
| 3-1/2 | 4.250 | 12 | NUE 10 RD or EUE 8 RD | 50.000 to 70.000 | 02-10.30-3.500 |
| 4 | 4.750 | 12 | NUE 8 RD or EUE 8 RD | 50.000 to 70.000 | 02-10.30-4.500 |
Notes:
*) this specification is subject to ± 5% tolerance.
*) other grade and size are available based on request
*) this specification is subject to ± 5% tolerance.
*) other grade and size are available based on request
Product Picture
